SPECIFICATION
| MODEL | EM390-A | Crankshaft output type | |
| ENGINE TYPE | SINGLE CYLINDER,4-STROKE,OHV,FORCED AIR COOLING |  |  |
| DISPLACEMENT(CC) | 389 | ||
| BORE X STROKE(MM) | 88X64 | ||
| MAX.OUTPUT(KW)(R/MIN) | 7.6/3600 | ||
| MAX.TORQUE(N.M)(RPM) | 23/2500 | 14300-D030011 | 14300-D030021 |
| COMPRESSION RATIO | 8.2:1 |  |  |
| ENGINE OIL CAPACITY(L) | 1 | ||
| FUEL | UNLEADED GASOLINE | ||
| FUEL TANK CAPACITY(L) | 6.5 | ||
| NET WEIGHT(KG) | 30.5 | ||
| DIMENSION(MM) | 460X400X435 | 14300-D030111 | 14300-D030121 |
